True E9: the water level sensor lost its signal
True reads the sump level through a small tube that carries air pressure to a sensing chip on the board.
Mon–Sat, 8am–8pm
- Sensors and bin control
- Ice machine bin control repair
- Source: True Residential
Book a visit
Three short steps, about a minute.
or call (844) 410-9163
Loading appointment form…
The appointment form couldn’t load. Please try again.
What E9
actually means.
True reads the sump level through a small tube that carries air pressure to a sensing chip on the board. E9 points to that tube being damaged or kinked, or to the chip not seating properly, and the fill, purge and leak checks cannot work without it.
True Residential ice machine display
What to do when E9 shows on the ice machineKind of codeSensors and bin control
A sensor is telling the board something that is not true: a bin control that reads full on an empty bin, or empty while ice spills over the top, a curtain switch stuck open, a temperature sensor out of range, or an eye on a dispenser that no longer sees the cup. Scale and slime on a probe or an ultrasonic sensor cause much of it. Clearing ice piled against the bin control is a safe first step; testing and replacing a sensor is a technician's.
Usually leads toIce machine bin control repair
The thermostat bulb, paddle, curtain switch or electronic eye that senses a full bin, adjusted or replaced so the machine stops and restarts on time.
Shows up asIce Machine Error Code or Flashing Light: What It Is Telling You
An ice machine error code may show as a number on a small display, a pattern of blinking lights on the control board, a colored light on the front, or a machine that stops with one indicator flashing.
MakeTrue Residential
True ice machine visits begin with the installation: the supply, the drain fall and the clearance the machine needs to cool.
SourceTrue Ice TCIM modular ice machine service manual (TEC_TM_198 Rev A)
True Ice TCIM air-cooled modular heads (TCIM-422 to TCIM-830), touchscreen control; the code shows on the active alarm screen and stays in the alarm log.
Before you book,
in this order.
Each step comes from True Residential's own guidance for E9 on its ice machines. Follow it to the end: the last card says whether this is a visit.
Turn the head off at the touchscreen.
If you can see the sensing tube from the sump without removing any panel, check it for kinks or a loose end.
Book a visit; the tube and the board contact are checked with the covers off and power isolated.
Still there?
It usually turns into ice machine bin control repair. Book with the code and the model number.
What not to do
E9 is a lost signal, not a real fill or drain problem, although it can stop both. E23, a level calculation alarm, is a different event read by a technician in the log.
What you may
notice with it.
The ice machine problems E9 tends to arrive with. Answer these at the ice machine before anyone is booked.
All problems
Where E9 usually leads
Ice machine bin control repair.
True Residential
ice machines.
True ice machine visits begin with the installation: the supply, the drain fall and the clearance the machine needs to cool.
True Residential ice machine repairMore True Residential codes
All 15 True Residential codesSensors and bin control on other makes
In True Residential's own words
ALARM Water Level Sensor Input
Every code on this site is taken from the manufacturer's documentation, never from a forum or a parts listing. True Ice TCIM air-cooled modular heads (TCIM-422 to TCIM-830), touchscreen control; the code shows on the active alarm screen and stays in the alarm log.
True Residential E9 ice machine repair,
where we come out.
The same visit in every metro below: the code, the model number, and a diagnosis before any part is ordered.
All service areasTampa BayFL · 31 areas
Miami / South FloridaFL · 47 areas
New York MetroNY · 75 areas
HoustonTX · 36 areas
ChicagoIL · 50 areas
Los AngelesCA · 95 areas
San DiegoCA · 31 areas
Questions
about E9.
Can I clear E9 myself?
How does a True ice machine know how much water is in the sump?
Can cleaning cause E9 on my True?
Will my True make ice with E9?
Back to your everyday
Still showing E9?
A booking with a code goes further when it carries the light or code copied as it appeared, the model and serial off the data plate, and a word on whether cubes still fall into the bin. With those three in hand, our office can match the probable part to your machine the same afternoon.
