Ice machine
error codes,
read properly.

The water side came up short: the trough did not fill in the time allowed, the float or level probe never saw water, or water kept flowing when the inlet valve should have closed. A supply valve left partly shut, a clogged filter cartridge, low building pressure or a sticking inlet valve are the usual causes. Opening the valve fully and fitting a fresh filter clears the simple cases; a valve that hums without passing water is a visit.

Usually leads to

Ice machine water valve and filter repair

Shows up as

Ice Machine Running but Not Making IceIce Machine Making Too Little Ice for the RushIce Machine Cubes Coming Out Thin, Small or HollowIce Machine Water Running Nonstop to the DrainIce Machine Error Code or Flashing Light: What It Is Telling You

A freeze ran longer than the board allows, or a harvest started and the ice never fell. Scale on the evaporator holds the sheet to the plate, a thickness probe crusted with minerals never signals, a hot gas valve that does not open leaves the plate cold, a harvest assist that does not push, or a water curtain that swings without tripping its switch all end in this family. A cleaning cycle run by the manual often clears it; a valve or a probe is a technician's job.

Usually leads to

Ice machine harvest repair

Shows up as

Ice Machine Not Harvesting: Ice Stays Stuck on the PlateIce Machine Making Too Little Ice for the RushIce Machine Cubes Coming Out Thin, Small or HollowCloudy, Soft or Wet Ice From an Ice MachineIce Machine Error Code or Flashing Light: What It Is Telling You

The board saw temperatures or pressures that the sealed system should never reach: a discharge line too hot, a suction side that never cools, or a compressor that starts and stops on its overload. A dirty condenser can push a healthy system into this family, so it is the first thing to rule out; a low charge, a leak or a tired compressor is not. On many current machines that system holds R-290, which is flammable, and only a technician opens it.

Usually leads to

Ice machine compressor and sealed system repair

Shows up as

Ice Machine Running but Not Making IceIce Machine Making Too Little Ice for the RushIce Machine Loud: Grinding, Rattling or BangingIce Machine Tripping the Breaker or Blowing a FuseHissing or a Gas Smell Near an Ice Machine on R-290Ice Machine Error Code or Flashing Light: What It Is Telling You

The machine could not shed its heat. An air filter packed with lint, a condenser coil furred with grease and dust, a fan motor that no longer spins, a machine pushed into a hot corner without its clearance, a water-cooled condenser whose regulating valve starves it, or a remote condenser on a roof blocked by leaves all show up here. Washing the air filter and freeing the space around the machine clears many cases; a fan motor or a valve means a visit.

Usually leads to

Ice machine condenser and fan repair

Shows up as

Ice Machine Making Too Little Ice for the RushIce Machine Loud: Grinding, Rattling or BangingIce Machine Running but Not Making IceIce Machine Error Code or Flashing Light: What It Is Telling You

Water that should have left the machine is still inside it. A gravity drain clogged with slime or scale, a line run too flat to keep up during a harvest, a drain pump whose float sticks or whose motor has stopped, or an air gap blocked at the floor sink all back water into the bin or across the floor. Checking that the drain outlet in view runs clear is a fair first step; the pump and the line inside the cabinet are a visit.

Usually leads to

Ice machine drain and pump repair

Shows up as

Ice Machine Drain Backing Up Into the BinIce Machine Leaking Water Across the Floor or Under the BinSlime or Mold Growing in the Ice Machine BinIce Machine Error Code or Flashing Light: What It Is Telling You

A sensor is telling the board something that is not true: a bin control that reads full on an empty bin, or empty while ice spills over the top, a curtain switch stuck open, a temperature sensor out of range, or an eye on a dispenser that no longer sees the cup. Scale and slime on a probe or an ultrasonic sensor cause much of it. Clearing ice piled against the bin control is a safe first step; testing and replacing a sensor is a technician's.

Usually leads to

Ice machine bin control repair

Shows up as

Ice Bin Full but the Ice Machine Keeps Making IceIce Machine Running but Not Making IceIce Dispenser Not Dispensing Ice or WaterIce Machine Error Code or Flashing Light: What It Is Telling You

The board lost track of itself or of its power: a voltage too low or too high at startup, a relay that no longer closes, a keypad or display that stays dark, or a memory error after a surge. Switching off at the machine's own switch for a minute clears a passing glitch. A code that returns, a breaker that trips, or any hot or burning smell means the power stays off and the board, the wiring and the relays are left to a technician.

Usually leads to

Ice machine control board repair

Shows up as

Ice Machine Running but Not Making IceIce Machine Tripping the Breaker or Blowing a FuseBurning or Hot Electrical Smell From an Ice MachineIce Dispenser Not Dispensing Ice or WaterIce Machine Error Code or Flashing Light: What It Is Telling You
