What E12
actually means.
T1 sits at the evaporator outlet and tracks how cold the plate gets. When it reads over 113°F, True's first suspects are warm incoming water and a hot room, then the probe itself.
True Residential ice machine display
What to do when E12 shows on the ice machineKind of codeCooling system
The board saw temperatures or pressures that the sealed system should never reach: a discharge line too hot, a suction side that never cools, or a compressor that starts and stops on its overload. A dirty condenser can push a healthy system into this family, so it is the first thing to rule out; a low charge, a leak or a tired compressor is not. On many current machines that system holds R-290, which is flammable, and only a technician opens it.
Usually leads toIce machine compressor and sealed system repair
The compressor, its start parts and the sealed system, including machines on flammable R-290, tested for pressure and leaks and repaired by the maker's procedure.
Shows up asIce Machine Error Code or Flashing Light: What It Is Telling You
An ice machine error code may show as a number on a small display, a pattern of blinking lights on the control board, a colored light on the front, or a machine that stops with one indicator flashing.
MakeTrue Residential
True ice machine visits begin with the installation: the supply, the drain fall and the clearance the machine needs to cool.
SourceTrue Ice TCIM modular ice machine service manual (TEC_TM_198 Rev A)
True Ice TCIM air-cooled modular heads (TCIM-422 to TCIM-830), touchscreen control; the code shows on the active alarm screen and stays in the alarm log.
Before you book,
in this order.
Each step comes from True Residential's own guidance for E12 on its ice machines. Follow it to the end: the last card says whether this is a visit.
Check that the head is plumbed to a cold water line, not a hot or mixed one.
Check the room temperature and airflow around the head.
If the water and room are normal, book a visit so T1 can be measured with a meter.
Still there?
It usually turns into ice machine compressor and sealed system repair. Book with the code and the model number.
What not to do
E12 is a high reading, while E13 is the opposite limit, below -20°F, and E1 means T1 is open or shorted. It does not mean the machine is harvesting too long; that is E26.
What you may
notice with it.
The ice machine problems E12 tends to arrive with. Answer these at the ice machine before anyone is booked.
All problems
Where E12 usually leads
Ice machine compressor and sealed system repair.
True Residential
ice machines.
True ice machine visits begin with the installation: the supply, the drain fall and the clearance the machine needs to cool.
True Residential ice machine repairMore True Residential codes
All 15 True Residential codesCooling system on other makes
All 11 codes of this kind
In True Residential's own words
Evaporator outlet temp exceeded 113˚F (45˚C)
Every code on this site is taken from the manufacturer's documentation, never from a forum or a parts listing. True Ice TCIM air-cooled modular heads (TCIM-422 to TCIM-830), touchscreen control; the code shows on the active alarm screen and stays in the alarm log.
True Residential E12 ice machine repair,
where we come out.
The same visit in every metro below: the code, the model number, and a diagnosis before any part is ordered.
All service areasTampa BayFL · 31 areas
Miami / South FloridaFL · 47 areas
New York MetroNY · 75 areas
HoustonTX · 36 areas
ChicagoIL · 50 areas
Los AngelesCA · 95 areas
San DiegoCA · 31 areas
Questions
about E12.
Can I clear E12 myself?
Can a hot water connection cause E12 on a True ice machine?
Is E12 a probe problem on my True?
Will the machine keep running with E12?
Back to your everyday
Still showing E12?
A booking with a code goes further when it carries the light or code copied as it appeared, the model and serial off the data plate, and a word on whether cubes still fall into the bin. With those three in hand, our office can match the probable part to your machine the same afternoon.
